Chérubin transistors
Grammont (Radiofotos, Fotos); Paris, Malakoff
- Country
- France
- Manufacturer / Brand
- Grammont (Radiofotos, Fotos); Paris, Malakoff
- Year
- 1960/1961 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 213498
-
- alternative name: Radiofotos || Société des lampes Fotos
Publicité modèle
- Number of Transistors
- 7
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz
- Wave bands
- Broadcast, Long Wave and 2 x Short Wave.
- Power type and voltage
- Dry Batteries / 6 x 1.5 or 2 x 4.5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 0.325 W (unknown quality)
- Material
- Leather / canvas / plastic - over other material
- from Radiomuseum.org
- Model: Chérubin [transistors] - Grammont Radiofotos, Fotos;
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 290 x 200 x 100 mm / 11.4 x 7.9 x 3.9 inch
- Notes
-
4 gammes d'ondes dont 2 OC de 15.4 à 53.5 m. Clavier 5 touches. Cadre ferrite et antenne téléscopique integrés. HP elliptique de 12 x 19 cm. Prise antenne voiture et HPS.
Coffret bois gainé.
- Net weight (2.2 lb = 1 kg)
- 3 kg / 6 lb 9.7 oz (6.608 lb)
- Price in first year of sale
- 355.00 FRF
- Mentioned in
- -- Original prospect or advert
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- Radio Constructeur et Dépanneur (Juin 1961 / Les récepteurs français à transistors)
- Author
- Model page created by Oswald Bettendorf. See "Data change" for further contributors.
