Fortunio 23517

Fortunio 23517; Grammont Radiofotos, (ID = 1960008) Radio Fortunio 23517; Grammont Radiofotos, (ID = 1960009) Radio
Fortunio 23517; Grammont Radiofotos, (ID = 1960010) Radio Fortunio 23517; Grammont Radiofotos, (ID = 1960011) Radio
Fortunio 23517; Grammont Radiofotos, (ID = 1960012) Radio Fortunio 23517; Grammont Radiofotos, (ID = 1960013) Radio
Fortunio 23517; Grammont Radiofotos, (ID = 1960014) Radio Fortunio 23517; Grammont Radiofotos, (ID = 1960015) Radio
Fortunio 23517; Grammont Radiofotos, (ID = 1960016) Radio Fortunio 23517; Grammont Radiofotos, (ID = 1960017) Radio
Use red slider bar for more.
Fortunio 23517; Grammont Radiofotos, (ID = 1960008) Radio
Grammont Radiofotos,: Fortunio 23517 [Radio] ID = 1960008 1000x625
Select picture or schematic to display from thumbnails on the right and click for download.
For model Fortunio 23517, Grammont (Radiofotos, Fotos); Paris, Malakoff:
Vue de face du récepteur

Country:  France
Manufacturer / Brand:  Grammont (Radiofotos, Fotos); Paris, Malakoff
alternative name

Radiofotos || Société des lampes Fotos
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: EF93 ECH81 EBF89 EBF80 EM81 EL84 EZ80
Main principle Superhet with RF-stage; ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
Power out 4 W (max.)
from Radiomuseum.org Model: Fortunio 23517 - Grammont Radiofotos, Fotos;
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 487 x 328 x 230 mm / 19.2 x 12.9 x 9.1 inch
Notes

2 OC dont une bande étalée (BE, 49m band).

Net weight (2.2 lb = 1 kg) 9 kg / 19 lb 13.2 oz (19.824 lb)

Model page created by Jean-Pierre Ambroise. See "Data change" for further contributors.
