945 BX
Use red slider bar for more.
Select picture or schematic to display from thumbnails on the right and click for download.
|
|
||||
|
alternative name
|
Grundig Portugal || Grundig USA / Lextronix | ||||
|---|---|---|---|---|---|
| Year: 1953/1954 | Category: Broadcast Receiver - or past WW2 Tuner | ||||
| Valves / Tubes | 4: DK92 DF91 or 1T4 DAF91 or 1S5 DL94 |
| Main principle | Superheterodyne (common); ZF/IF 468 kHz |
|---|---|
| Tuned circuits | 6 AM circuit(s) |
| Wave bands | Broadcast plus more than 2 Short Wave bands. |
| Details | |
| Power type and voltage | Storage and/or dry batteries / 90 & 1,5 Volt |
| Loudspeaker | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) |
| Power out | |
| from Radiomuseum.org | Model: 945 BX - Grundig Radio-Vertrieb, RVF, |
| Shape | Tablemodel with Push Buttons. |
| Notes | Exportgerät mit Mittelwelle und 3x Kurzwelle; auch über separates Netzteil zu betreiben |
| Literature/Schematics (1) | -- Original-techn. papers. |
Model page created by Josef Pilz. See "Data change" for further contributors.
