• Year
  • 1970 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 183205
    • alternative name: Grundig Portugal || Grundig USA / Lextronix

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 38900 kHz
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.5 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Exclusiv 2050 electronic - Grundig Radio-Vertrieb, RVF,
  • Shape
  • Tablemodel, low profile (big size).
  • Notes
  • Grundig Exclusiv 2050 electronic;
    ~60 cm s/w TV mit elektronischem CCIR B/G 7 Programmtasten Tuner.
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.
