Oszillograph G5

Oszillograph G5; Grundig Radio- (ID = 961757) Equipment

Oszillograph G5; Grundig Radio- (ID = 961758) Equipment

Oszillograph G5; Grundig Radio- (ID = 961816) Equipment

Oszillograph G5; Grundig Radio- (ID = 961819) Equipment

Oszillograph G5; Grundig Radio- (ID = 961822) Equipment
Oszillograph G5; Grundig Radio- (ID = 1008950) Equipment Oszillograph G5; Grundig Radio- (ID = 1008952) Equipment
Oszillograph G5; Grundig Radio- (ID = 961823) Equipment Oszillograph G5; Grundig Radio- (ID = 237379) Equipment
Oszillograph G5; Grundig Radio- (ID = 1008951) Equipment Oszillograph G5; Grundig Radio- (ID = 1008953) Equipment
Oszillograph G5; Grundig Radio- (ID = 1008954) Equipment Oszillograph G5; Grundig Radio- (ID = 1008955) Equipment
Oszillograph G5; Grundig Radio- (ID = 1498969) Equipment Oszillograph G5; Grundig Radio- (ID = 1552210) Equipment
Use red slider bar for more.
Oszillograph G5; Grundig Radio- (ID = 1008950) Equipment
Grundig Radio-: Oszillograph G5 [Equipment] ID = 1008950 574x921
Select picture or schematic to display from thumbnails on the right and click for download.
For model Oszillograph G5, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1960 Category: Service- or Lab Equipment
Valves / Tubes 9: PCC85 PCC85 PCC88 PCC88 PCF82 PCF80 EZ80 EZ80 ES11 DG7-74A
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oszillograph G5 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Dimensions (WHD) 130 x 260 x 400 mm / 5.1 x 10.2 x 15.7 inch
Notes Grundig Oszillograph G5.
Bandbreite: 0 bis 5 MHz, Empfindlichkeit: 18 mVss/cm.
Net weight (2.2 lb = 1 kg) 8.1 kg / 17 lb 13.5 oz (17.841 lb)
Price in first year of sale 13'120.00 BFr
Collectors' prices
Source of data -- Original prospect or advert

Model page created by Hugo Sneyers. See "Data change" for further contributors.
