GDM10

GDM10; Grundig Radio- (ID = 1014163) Microphone/PU
GDM10; Grundig Radio- (ID = 176485) Microphone/PU GDM10; Grundig Radio- (ID = 176486) Microphone/PU
GDM10; Grundig Radio- (ID = 725289) Microphone/PU GDM10; Grundig Radio- (ID = 967706) Microphone/PU
GDM10; Grundig Radio- (ID = 1325997) Microphone/PU GDM10; Grundig Radio- (ID = 1367120) Microphone/PU
GDM10; Grundig Radio- (ID = 1367121) Microphone/PU GDM10; Grundig Radio- (ID = 1367122) Microphone/PU
GDM10; Grundig Radio- (ID = 2061929) Microphone/PU GDM10; Grundig Radio- (ID = 2061930) Microphone/PU
Use red slider bar for more.
GDM10; Grundig Radio- (ID = 176485) Microphone/PU
Grundig Radio-: GDM10 [Microphone/PU] ID = 176485 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model GDM10, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1956 Category: Microphone or Pick-up element
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: GDM10 - Grundig Radio-Vertrieb, RVF,
Material Various materials
Dimensions (WHD) 59 x 78 x 35 mm / 2.3 x 3.1 x 1.4 inch
Notes Mikrofon mit Nierencharakteristik, Thermoplastgehäuse und ausklappbarem Fuß aus Messing. Stoffummanteltes Anschlußkabel mit 3-poligem DIN-Stecker. Integrierter Impedanzwandler 0,1/3,9kOhm
Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 48.00 DM
Collectors' prices
Source of data - - Data from my own collection

Model page created by Wolfgang Winkler. See "Data change" for further contributors.
