Hit-Boy N210

Hit-Boy N210; Grundig Radio- (ID = 156946) Radio

Hit-Boy N210; Grundig Radio- (ID = 156947) Radio

Hit-Boy N210; Grundig Radio- (ID = 156950) Radio

Hit-Boy N210; Grundig Radio- (ID = 156951) Radio

Hit-Boy N210; Grundig Radio- (ID = 156948) Radio

Hit-Boy N210; Grundig Radio- (ID = 156949) Radio

Hit-Boy N210; Grundig Radio- (ID = 848594) Radio

Hit-Boy N210; Grundig Radio- (ID = 1488453) Radio

Hit-Boy N210; Grundig Radio- (ID = 1488455) Radio

Hit-Boy N210; Grundig Radio- (ID = 1488456) Radio
Hit-Boy N210; Grundig Radio- (ID = 288992) Radio Hit-Boy N210; Grundig Radio- (ID = 831896) Radio
Hit-Boy N210; Grundig Radio- (ID = 831897) Radio Hit-Boy N210; Grundig Radio- (ID = 288993) Radio
Hit-Boy N210; Grundig Radio- (ID = 509813) Radio Hit-Boy N210; Grundig Radio- (ID = 924731) Radio
Hit-Boy N210; Grundig Radio- (ID = 2224429) Radio
Use red slider bar for more.
Hit-Boy N210; Grundig Radio- (ID = 288992) Radio
Grundig Radio-: Hit-Boy N210 [Radio] ID = 288992 672x651
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hit-Boy N210, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: 2SC668 2SC772 2SC829 2SB171 2SB175 2SB22 2SB22 LA1201
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Short Wave plus FM or UHF.
Details
Power type and voltage Line / Batteries (any type) / 220; (4 × 1,5) Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 9 cm = 3.5 inch
Power out
from Radiomuseum.org Model: Hit-Boy N210 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 240 x 145 x 60 mm / 9.4 x 5.7 x 2.4 inch
Notes ICs: 1.
KW-Lupe.
Net weight (2.2 lb = 1 kg) 1.2 kg / 2 lb 10.3 oz (2.643 lb)
Mentioned in -- Original-techn. papers.

Model page created by Daniel Doll. See "Data change" for further contributors.



All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6057 models, 5282 with images and 4090 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
