Majestic Niki SKL/E

Majestic Niki SKL/E; Grundig Radio- (ID = 832763) R-Player

Majestic Niki SKL/E; Grundig Radio- (ID = 832614) R-Player

Majestic Niki SKL/E; Grundig Radio- (ID = 832615) R-Player
Majestic Niki SKL/E; Grundig Radio- (ID = 1652046) R-Player Majestic Niki SKL/E; Grundig Radio- (ID = 491265) R-Player
Majestic Niki SKL/E; Grundig Radio- (ID = 833602) R-Player Majestic Niki SKL/E; Grundig Radio- (ID = 833603) R-Player
Majestic Niki SKL/E; Grundig Radio- (ID = 833604) R-Player Majestic Niki SKL/E; Grundig Radio- (ID = 833605) R-Player
Majestic Niki SKL/E; Grundig Radio- (ID = 1473275) R-Player Majestic Niki SKL/E; Grundig Radio- (ID = 1473276) R-Player
Majestic Niki SKL/E; Grundig Radio- (ID = 1652045) R-Player Majestic Niki SKL/E; Grundig Radio- (ID = 1652047) R-Player
Use red slider bar for more.
Majestic Niki SKL/E; Grundig Radio- (ID = 1652046) R-Player
Grundig Radio-: Majestic Niki SKL/E [R-Player] ID = 1652046 933x559
Select picture or schematic to display from thumbnails on the right and click for download.
For model Majestic Niki SKL/E, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1959 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 6: OC71 OC72 OC72 OC74 OC75 OC602
Details Tape Recorder
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.1 W (unknown quality)
from Radiomuseum.org Model: Majestic Niki SKL/E - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 11 x 7 x 3 inch / 279 x 178 x 76 mm
Notes

Grundig Niki SKL/E.
Externe Speisung möglich mit NIKI-Netzanschlussgerät.



Net weight (2.2 lb = 1 kg) 2.5 kg / 5 lb 8.1 oz (5.507 lb)
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Dte 5-61 title copy)
Literature/Schematics (2) Funk-Technik (FT) (23/1959, S. 828 / Beschreibung, Schema)

Model page created by Alard Roose. See "Data change" for further contributors.



All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6056 models, 5279 with images and 4088 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
