For model Oszilloskop GO10, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1973 Category: Service- or Lab Equipment
Valves / Tubes 1: D13-480GH
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Oszilloskop GO10 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 270 x 410 mm / 11.8 x 10.6 x 16.1 inch
Notes Zweikanal-Oszilloskop mit 2 kV Beschleunigungsspannung, 10 MHz Bandbreite der Y-Verstärker.
Net weight (2.2 lb = 1 kg) 9.8 kg / 21 lb 9.4 oz (21.586 lb)
Price in first year of sale 1'770.00 DM
Mentioned in Grundig Technische Informationen 2/1973
