Resonanzmeter II (2) 701

Resonanzmeter II 701; Grundig Radio- (ID = 254160) Equipment

Resonanzmeter II 701; Grundig Radio- (ID = 254202) Equipment

Resonanzmeter II 701; Grundig Radio- (ID = 254203) Equipment

Resonanzmeter II 701; Grundig Radio- (ID = 254204) Equipment

Resonanzmeter II 701; Grundig Radio- (ID = 254205) Equipment

Resonanzmeter II 701; Grundig Radio- (ID = 2040285) Equipment
Resonanzmeter II 701; Grundig Radio- (ID = 615380) Equipment Resonanzmeter II 701; Grundig Radio- (ID = 615381) Equipment
Resonanzmeter II 701; Grundig Radio- (ID = 2240094) Equipment Resonanzmeter II 701; Grundig Radio- (ID = 301329) Equipment
Resonanzmeter II 701; Grundig Radio- (ID = 301328) Equipment Resonanzmeter II 701; Grundig Radio- (ID = 237595) Equipment
Resonanzmeter II 701; Grundig Radio- (ID = 301327) Equipment Resonanzmeter II 701; Grundig Radio- (ID = 301330) Equipment
Resonanzmeter II 701; Grundig Radio- (ID = 615382) Equipment Resonanzmeter II 701; Grundig Radio- (ID = 615383) Equipment
Use red slider bar for more.
Resonanzmeter II 701; Grundig Radio- (ID = 615380) Equipment
Grundig Radio-: Resonanzmeter II 701 [Equipment] ID = 615380 933x546
Select picture or schematic to display from thumbnails on the right and click for download.
For model Resonanzmeter II (2) 701, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1957–1966 Category: Service- or Lab Equipment
Valves / Tubes 1: EC92
Semiconductors (the count is only for transistors) Tr.Gl.=Metal-rectif.
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Resonanzmeter II 701 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Dimensions (WHD) 75 x 200 x 55 mm / 3 x 7.9 x 2.2 inch
Notes

Grid-Dipp-Meter mit 4 Betriebsarten: Empfänger, Gitter-Dipper, Absorptions-Wellenmesser, Prüf-Sender mit 50 Hz moduliert. 6 Resonanzkreise: 1,7···3,7 MHz, 3,7···8 MHz, 8···17 MHz, 17···40 MHz, 40···100 MHz, 100···250 MHz; Frequenzgenauigkeit: ±1,5 %.

Preisangabe von 1957/58.
Preis 1966: 270,-DM (Katalog Hannes Bauer).

Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Price in first year of sale 155.00 DM
Collectors' prices
Mentioned in Handbuch RFP 1957 (Hdb. für Rundfunk Phono Fernsehen 1957/58, Verlag Thiele, Helmstedt)
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) Katalog Hannes Bauer, 1966

Model page created by a member from A. See "Data change" for further contributors.
