- Country
- Germany
- Manufacturer / Brand
- Grundig (Radio-Vertrieb, RVF, Radiowerke)
- Year
- 1968 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 159209
-
- alternative name: Grundig Portugal || Grundig USA / Lextronix
Bild aus eBay
Bild aus eBay
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 9
- Semiconductors
- BF185 BF184 BF195 BF194 BF195 BC148 BC148 AC187 AC188 AA116 AA116 1N60 ZF12 B30C350 B30C350
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz; 2 AF stage(s); Export model
- Tuned circuits
- 7 AM circuit(s) 11 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
- Power out
- 2 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: RF80U - Grundig Radio-Vertrieb, RVF,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 395 x 175 x 125 mm / 15.6 x 6.9 x 4.9 inch
- Notes
-
Nordamerika-Export 115V 60Hz, Leistungsaufnahme max. 6W.
Siehe auch die europäische Versionen Grundig RF110, RF110a und RF110a GB mit jeweils zusätzlichem LW-Bereich.
- Net weight (2.2 lb = 1 kg)
- 2.5 kg / 5 lb 8.1 oz (5.507 lb)
- Mentioned in
- -- Original-techn. papers.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1971 Component Stereo #2)
- Author
- Model page created by Ralf Nolde. See "Data change" for further contributors.
