Stereo-Konzertschrank SO205 poliert

Stereo-Konzertschrank SO205; Grundig Radio- (ID = 27303) Radio

Stereo-Konzertschrank SO205; Grundig Radio- (ID = 27304) Radio

Stereo-Konzertschrank SO205; Grundig Radio- (ID = 27305) Radio

Stereo-Konzertschrank SO205; Grundig Radio- (ID = 27306) Radio
Stereo-Konzertschrank SO205; Grundig Radio- (ID = 184198) Radio
Use red slider bar for more.
Stereo-Konzertschrank SO205; Grundig Radio- (ID = 184198) Radio
Grundig Radio-: Stereo-Konzertschrank SO205 [Radio] ID = 184198 511x610
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo-Konzertschrank SO205 poliert, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1961/1962 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EBF89 ECC83 EM84 ELL80
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     10 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 125; 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Stereo-Konzertschrank SO205 [poliert] - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 640 x 800 x 370 mm / 25.2 x 31.5 x 14.6 inch
Notes Stereo-NF-Verstärker mit 2 Endstufen je 3 W. Phono-Chassis = Perpetuum-Ebner PE66.
Net weight (2.2 lb = 1 kg) 20 kg / 44 lb 0.8 oz (44.053 lb)
Price in first year of sale 565.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1961/62
Mentioned in Guida Pratica Antique Radio III (2000)
