For model TK121, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Grundig TK121, Gesamtansicht.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1969–1973 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) 10: BC107 BC107 BC183 BC183 BC108 BC109 BC181 BF257 AD161 AD162
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 115; 220; 230 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 4 W (unknown quality)
from Radiomuseum.org Model: TK121 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 390 x 160 x 290 mm / 15.4 x 6.3 x 11.4 inch
Notes Zweispur-Mono; Bandgeschwindigkeit: 9,5 cm/s; Spulen-Ø: 15 cm; Übertragungsbereich: 40-12500 Hz.
Net weight (2.2 lb = 1 kg) 8 kg / 17 lb 9.9 oz (17.621 lb)
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1969/1970
