TM20; Grundig Radio- (ID = 54465) R-Player
Grundig Radio-: TM20 [R-Player] ID = 54465 500x375
Select picture or schematic to display from thumbnails on the right and click for download.
For model TM20, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1958–1960 Category: Sound/Video Recorder and/or Player
Valves / Tubes 4: EF86 ECC81 EL95 EM84
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker
Power out
from Radiomuseum.org Model: TM20 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 350 x 320 x 180 mm / 13.8 x 12.6 x 7.1 inch
Notes Technische Daten wie TK20, jedoch Einbau-Chassis ohne Koffer, Lautsprecher und Verstärker-Endstufe.
Net weight (2.2 lb = 1 kg) 9.5 kg / 20 lb 14.8 oz (20.925 lb)
Price in first year of sale 335.00 DM
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1960/61


All listed radios etc. from Grundig (Radio-Vertrieb, RVF, Radiowerke)
Here you find 6070 models, 5290 with images and 4087 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Grundig Radio-: TM20
Threads: 1 | Posts: 1
Hits: 1879     Replies: 0
grundig: Grundig Tonband TM20 In welchem Radio eingebaut?
Martin Schmidt2
23.Dec.07
  1

Hallo,

habe hier noch ein TM20 von Grundig als Einbauchassis.In welchen Radios oder Musiktruhen war es verbaut?



Viele Grüsse

Martin
