Record TK820/3D

Record TK820/3D; Grundig Radio- (ID = 433733) R-Player

Record TK820/3D; Grundig Radio- (ID = 433734) R-Player

Record TK820/3D; Grundig Radio- (ID = 433739) R-Player

Record TK820/3D; Grundig Radio- (ID = 433740) R-Player

Record TK820/3D; Grundig Radio- (ID = 433738) R-Player

Record TK820/3D; Grundig Radio- (ID = 433741) R-Player

Record TK820/3D; Grundig Radio- (ID = 433737) R-Player

Record TK820/3D; Grundig Radio- (ID = 433736) R-Player

Record TK820/3D; Grundig Radio- (ID = 13486) R-Player

Record TK820/3D; Grundig Radio- (ID = 630933) R-Player
Record TK820/3D; Grundig Radio- (ID = 1791140) R-Player Record TK820/3D; Grundig Radio- (ID = 358199) R-Player
Record TK820/3D; Grundig Radio- (ID = 36542) R-Player Record TK820/3D; Grundig Radio- (ID = 363116) R-Player
Record TK820/3D; Grundig Radio- (ID = 53504) R-Player Record TK820/3D; Grundig Radio- (ID = 358200) R-Player
Record TK820/3D; Grundig Radio- (ID = 17896) R-Player Record TK820/3D; Grundig Radio- (ID = 363114) R-Player
Record TK820/3D; Grundig Radio- (ID = 363115) R-Player Record TK820/3D; Grundig Radio- (ID = 363119) R-Player
Use red slider bar for more.
Record TK820/3D; Grundig Radio- (ID = 1791140) R-Player
Grundig Radio-: Record TK820/3D [R-Player] ID = 1791140 1400x1308
Select picture or schematic to display from thumbnails on the right and click for download.
For model Record TK820/3D, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1955/1956 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: EF804 ECC81 EL42 EL84 EM71
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 165; 220 Volt
Loudspeaker 3 Loudspeakers
Power out 5 W (unknown quality)
from Radiomuseum.org Model: Record TK820/3D - Grundig Radio-Vertrieb, RVF,
Material Leather / canvas / plastic - over other material
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 240 x 410 mm / 16.9 x 9.4 x 16.1 inch
Notes Zweispur; 9,5/19cm/s. Spulen-Ø 18cm. Aufnahme und Wiedergabe in beiden Laufrichtungen, für jede Spur eigene Lösch- und Aufnahmeköpfe, elektromechanische Spurumschaltung. Gehäuse aus Holz mit Metall- und Kunststoffteilen. Wurde in Österreich für ATS 7900,- verkauft.
Net weight (2.2 lb = 1 kg) 21 kg / 46 lb 4.1 oz (46.256 lb)
Price in first year of sale 965.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1955/56
