For model Tongenerator TG4, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Grundig Tongenerator TG4
Photo by courtesy of A. Ricciarini

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1968 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 19: BF244 2N3819 BC107 BC177 2N3705 2N3703 BFY51 BD109 AD166 2N3054
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out 4 W (unknown quality)
from Radiomuseum.org Model: Tongenerator TG4 - Grundig Radio-Vertrieb, RVF,
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 300 x 218 x 176 mm / 11.8 x 8.6 x 6.9 inch
Notes

Frequenzbereich 30 ... 20000 Hz in einem Bereich kontinuierlich einstellbar. Das Gerät kann auch als Verstärker mit hochohmigem Eingang (1 MOhm) verwendet werden. In Verbindung mit einem externen Lautsprecher kann der Tongenerator auch als Signalverfolger Verwendung finden.
Ausgangsspannung Sinus- oder Rechteck-Form.
Spannungsbereich = 5 mVeff ... 5 Veff
Spannungsteiler = 4 Dekaden á 20 dB
Ausgangsimpedanz: 5/10/20 Ohm unsymmetrisch; 150/600 Ohm symmetrisch.
Jeder Transistortyp nur einmal gelistet.

Net weight (2.2 lb = 1 kg) 7 kg / 15 lb 6.7 oz (15.419 lb)
Price in first year of sale 810.00 DM
Mentioned in -- Original-techn. papers.
Literature/Schematics (1) - - Manufacturers Literature (Grundig Technische Informationen (TI) 4/1968, S.491 ff.)
