Transistor Luxus Boy 200 E Export

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487723) Radio

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487724) Radio

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487725) Radio

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487726) Radio

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487729) Radio

Transistor Luxus Boy 200 E; Grundig Radio- (ID = 487732) Radio
Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974329) Radio Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974331) Radio
Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974335) Radio Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974337) Radio
Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974338) Radio Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974339) Radio
Use red slider bar for more.
Transistor Luxus Boy 200 E; Grundig Radio- (ID = 1974329) Radio
Grundig Radio-: Transistor Luxus Boy 200 E [Radio] ID = 1974329 900x675
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transistor Luxus Boy 200 E Export, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 8: OC170 OC170 OC169 OC169 OC71 OC71 OC72 OC72
Main principle Superheterodyne (common); ZF/IF 460 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8.5 cm = 3.3 inch
Power out 0.3 W (unknown quality)
from Radiomuseum.org Model: Transistor Luxus Boy 200 E [Export] - Grundig Radio-Vertrieb, RVF,
Material Plastics (no bakelite or catalin)
Dimensions (WHD) 210 x 140 x 60 mm / 8.3 x 5.5 x 2.4 inch
Notes Grundig, Transistor Luxus Boy 200E.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Mentioned in Original Grundig Service Unterlagen

Model page created by Josef Pilz. See "Data change" for further contributors.
