Triumph Super Electronic 1215

Triumph Super Electronic 1215; Grundig Radio- (ID = 657033) Television

Triumph Super Electronic 1215; Grundig Radio- (ID = 657034) Television

Triumph Super Electronic 1215; Grundig Radio- (ID = 657036) Television

Triumph Super Electronic 1215; Grundig Radio- (ID = 657040) Television

Triumph Super Electronic 1215; Grundig Radio- (ID = 657049) Television
Triumph Super Electronic 1215; Grundig Radio- (ID = 2173268) Television Triumph Super Electronic 1215; Grundig Radio- (ID = 2173267) Television
Triumph Super Electronic 1215; Grundig Radio- (ID = 2173269) Television Triumph Super Electronic 1215; Grundig Radio- (ID = 2173272) Television
Triumph Super Electronic 1215; Grundig Radio- (ID = 2173273) Television Triumph Super Electronic 1215; Grundig Radio- (ID = 2173274) Television
Triumph Super Electronic 1215; Grundig Radio- (ID = 2173275) Television Triumph Super Electronic 1215; Grundig Radio- (ID = 2173277) Television
Triumph Super Electronic 1215; Grundig Radio- (ID = 444548) Television
Use red slider bar for more.
Triumph Super Electronic 1215; Grundig Radio- (ID = 2173268) Television
Grundig Radio-: Triumph Super Electronic 1215 [Television] ID = 2173268 1400x1216
Select picture or schematic to display from thumbnails on the right and click for download.
For model Triumph Super Electronic 1215, Grundig (Radio-Vertrieb, RVF, Radiowerke):
S/w-Testbild vom Mac über Videorecorder als UHF-Modulator in die Antennenbuchse eingespeist.
Gerät wurde dem 'BINARIUM' gespendet.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1973–1975 Category: Television Receiver (TV) or Monitor
Valves / Tubes 1: A31-120W
Semiconductors (the count is only for transistors) 17:
Main principle Superheterodyne (common)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Line / Batteries (any type) / 220 & 12 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Triumph Super Electronic 1215 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 300 x 260 x 270 mm / 11.8 x 10.2 x 10.6 inch
Notes 31 cm Portable, 7 IC´s, 33 Dioden, VHF/UHF-Tuner, beleuchtete Programmanzeige, Teleskop-Antenne. Gehäuse in weiß, gelb oder rot. Verkauf über die Weltfunk anlässlich der Funkausstellung 1975
Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Mentioned in -- Original-techn. papers. (Weiler Angebot 1973/74)

Model page created by Karlheinz Fischer. See "Data change" for further contributors.
