TS340; Grundig Radio- (ID = 2164224) R-Player
Grundig Radio-: TS340 [R-Player] ID = 2164224 1400x1042
Select picture or schematic to display from thumbnails on the right and click for download.
For model TS340, Grundig (Radio-Vertrieb, RVF, Radiowerke):
Gerät steht in einem Museum.

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1966–1968 Category: Sound/Video Recorder and/or Player
Valves / Tubes 6: EF86 EF86 ECC81 ECC81 EM84 EL95
Semiconductors (the count is only for transistors) 14: BFY39 BFY39 BFY39 BFY39 BSY76 BSY76 AC127 AC127 AC152 AC152 AD150 AD150 AD150 AD150
Main principle Audio-Amplification
Wave bands - without
Details Tape Recorder
Power type and voltage Alternating Current supply (AC) / 110; 130; 220; 240 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: TS340 - Grundig Radio-Vertrieb, RVF,
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 520 x 210 x 400 mm / 20.5 x 8.3 x 15.7 inch
Notes Dioden: DZ62, 2× M3, 2× Z1,5. Vierspur-Stereo;
Bandgeschwindigkeiten: 4,75/9,5/19 cm/s; Spulen-Ø 18 cm. Stereo-NF-Verstärker mit 2 Gegentakt-Endstufen je 12 Watt.
Net weight (2.2 lb = 1 kg) 17 kg / 37 lb 7.1 oz (37.445 lb)
Collectors' prices
External source of data erb
Source of data Handbuch VDRG 1966/1967
