Yacht-Boy 100

Yacht-Boy 100; Grundig Radio- (ID = 208658) Radio

Yacht-Boy 100; Grundig Radio- (ID = 208659) Radio

Yacht-Boy 100; Grundig Radio- (ID = 208660) Radio

Yacht-Boy 100; Grundig Radio- (ID = 208661) Radio

Yacht-Boy 100; Grundig Radio- (ID = 208662) Radio

Yacht-Boy 100; Grundig Radio- (ID = 208663) Radio

Yacht-Boy 100; Grundig Radio- (ID = 1453767) Radio

Yacht-Boy 100; Grundig Radio- (ID = 1453768) Radio
Yacht-Boy 100; Grundig Radio- (ID = 171983) Radio Yacht-Boy 100; Grundig Radio- (ID = 761045) Radio
Yacht-Boy 100; Grundig Radio- (ID = 191287) Radio Yacht-Boy 100; Grundig Radio- (ID = 761046) Radio
Yacht-Boy 100; Grundig Radio- (ID = 797220) Radio Yacht-Boy 100; Grundig Radio- (ID = 1457371) Radio
Yacht-Boy 100; Grundig Radio- (ID = 1457373) Radio Yacht-Boy 100; Grundig Radio- (ID = 1457375) Radio
Yacht-Boy 100; Grundig Radio- (ID = 1457376) Radio Yacht-Boy 100; Grundig Radio- (ID = 1457377) Radio
Use red slider bar for more.
Yacht-Boy 100; Grundig Radio- (ID = 171983) Radio
Grundig Radio-: Yacht-Boy 100 [Radio] ID = 171983 781x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Yacht-Boy 100, Grundig (Radio-Vertrieb, RVF, Radiowerke)

Country:  Germany
Manufacturer / Brand:  Grundig (Radio-Vertrieb, RVF, Radiowerke)
alternative name

Grundig Portugal || Grundig USA / Lextronix
Year: 1979–1981 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 16:
Main principle Superheterodyne (common); ZF/IF 460 / 10700 kHz
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Batteries / addl. power jack / AA: 5 x 1,5 / 7,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out 1 W (unknown quality)
from Radiomuseum.org Model: Yacht-Boy 100 - Grundig Radio-Vertrieb, RVF,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 230 x 140 x 30 mm / 9.1 x 5.5 x 1.2 inch
Notes

Der Yachtboy 100 ist ein kleiner Reiseempfänger mit 6 x KW von 16 bis 49 m. Tonregler. Aus Taste. Eine Anschlußbuchse für einen Kopfhörer und eine Buchse für ein externes Netzteil sind eingebaut.



Net weight (2.2 lb = 1 kg) 0.6 kg / 1 lb 5.1 oz (1.322 lb)
Price in first year of sale 250.00 DM
Source of data -- Original prospect or advert
Literature/Schematics (1) -- Original-techn. papers.
Literature/Schematics (2) - - Manufacturers Literature (Grundig Technische Informationen 4/5/1980)

Model page created by Wolfgang Bauer. See "Data change" for further contributors.
