Hario I (1)

Hario I ; Hario; Bruxelles (ID = 255003) Radio Hario I ; Hario; Bruxelles (ID = 255004) Radio
Hario I ; Hario; Bruxelles (ID = 255005) Radio Hario I ; Hario; Bruxelles (ID = 255006) Radio
Hario I ; Hario; Bruxelles (ID = 255007) Radio Hario I ; Hario; Bruxelles (ID = 1613709) Radio
Hario I ; Hario; Bruxelles (ID = 1613711) Radio Hario I ; Hario; Bruxelles (ID = 1613713) Radio
Hario I ; Hario; Bruxelles (ID = 1613716) Radio
Use red slider bar for more.
Hario I ; Hario; Bruxelles (ID = 255003) Radio
Hario; Bruxelles: Hario I [Radio] ID = 255003 640x432
Select picture or schematic to display from thumbnails on the right and click for download.
For model Hario I (1), Hario; Bruxelles

Country:  Belgium
Manufacturer / Brand:  Hario; Bruxelles
Year: 1935 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 78 75 43 25Z5
Main principle Super-Heterodyne (Super in general); 2 AF stage(s)
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 120; 220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 14 cm = 5.5 inch
Power out
from Radiomuseum.org Model: Hario I - Hario; Bruxelles
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 400 x 260 x 220 mm / 15.7 x 10.2 x 8.7 inch
Notes

This radio had a transportation suitcase as option: at the cost of 35 BFr.

Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Price in first year of sale 1'395.00 BFr
Source of data -- Original prospect or advert

Model page created by Jean-Luc Comblin. See "Data change" for further contributors.



All listed radios etc. from Hario; Bruxelles
Here you find 11 models, 7 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
