• Year
  • 1957/1958
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 22657

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 4 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: HM5 [1957] - Harting, Wilhelm; Espelkamp-
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 400 x 350 x 250 mm / 15.7 x 13.8 x 9.8 inch
  • Notes
  • Zweispur; 9,5/19 cm/s.; Spulen-Ø 18 cm.
  • Net weight (2.2 lb = 1 kg)
  • 14.5 kg / 31 lb 15 oz (31.938 lb)
  • Price in first year of sale
  • 648.00 DM
  • External source of data
  • Erb
