For model Premiere 53, HEA; Wien:
HEA Premiere 53

Country:  Austria
Manufacturer / Brand:  HEA; Wien
Year: 1952/1953 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH21 6BA6 6AT6 6AQ5 EM34 6X4
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Premiere 53 - HEA; Wien
Material Wooden case
Dimensions (WHD) 540 x 410 x 235 mm / 21.3 x 16.1 x 9.3 inch
Notes Info: www.radio-ghe.com: Senderabstimmung mit Drucktasten und Drehknopf. 3 x KW. Auch Allstromausführung zu 1950 S und Spezial für LW bzw. Drahtfunk zu 2050 S.
Net weight (2.2 lb = 1 kg) 9.6 kg / 21 lb 2.3 oz (21.145 lb)
Price in first year of sale 2'025.00 öS
Collectors' prices
Source of data -- Collector info (Sammler) / Radiokatalog Band 2, Ernst Erb
