PB51; Herofon / Herophon (ID = 450325) Radio
Herofon / Herophon: PB51 [Radio] ID = 450325 391x637
Select picture or schematic to display from thumbnails on the right and click for download.
For model PB51, Herofon / Herophon (brand of Hede Nielsen)

Country:  Denmark
Manufacturer / Brand:  Herofon / Herophon (brand of Hede Nielsen)
alternative name

Hede Nielsen's Fabrikker A/S
Year: 1948 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 1R5 1LN5 1LD5 3V4
Main principle Superheterodyne (common); ZF/IF 447 kHz; 1 AF stage(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Line / Batteries (any type) / 125 / 90 & 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
Power out 0.24 W (unknown quality)
from Radiomuseum.org Model: PB51 - Herofon / Herophon brand of
Material Moulded (Bakelite or Plastics)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 350 x 550 x 110 mm / 13.8 x 21.7 x 4.3 inch
Notes Frame aerial. Antena de cuadro, incorporada y extensible.
Net weight (2.2 lb = 1 kg) 2 kg / 4 lb 6.5 oz (4.405 lb)
Source of data - - Data from my own collection

Model page created by Ramon Mor Fernandez. See "Data change" for further contributors.
