For model Attaché 51 W451U, Horny (Hornyphon); Wien:
Hornyphon Attache51 W451U

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1951/1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: UCH42 UAF42 UBC41 UL41 UY41
Main principle Superheterodyne (common); ZF/IF 452 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set
Loudspeaker -Loudspeaker incorporated, but system not known. / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: Attaché 51 W451U - Horny Hornyphon; Wien
Material Bakelite case
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 365 x 250 x 205 mm / 14.4 x 9.8 x 8.1 inch
Notes ...
Net weight (2.2 lb = 1 kg) 4.3 kg / 9 lb 7.5 oz (9.471 lb)
Price in first year of sale 1'390.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
