For model Flirt DX6301 /00L /00B /00R, Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1970 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11: BF200 BF195 BF197 BF197 BC148 BC148 AC188 AC187 AC188 BC149 BC159
Main principle Superheterodyne (common); ZF/IF 10700 kHz
Tuned circuits 8 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Flirt DX6301 /00L /00B /00R - Horny Hornyphon; Wien
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 283 x 140 x 70 mm / 11.1 x 5.5 x 2.8 inch
Notes 3 Ausführungen:
../00L = rot
../00B = schwarz
../00R = schwarz
Netzgerät BT1A.
Parallelgerät zum Philips 66RL301.
Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Hannes Wurnitsch. See "Data change" for further contributors.
