Lord 39B W144 B

Lord 39B W144 B; Horny Hornyphon; (ID = 316345) Radio

Lord 39B W144 B; Horny Hornyphon; (ID = 9636) Radio

Lord 39B W144 B; Horny Hornyphon; (ID = 360041) Radio

Lord 39B W144 B; Horny Hornyphon; (ID = 360023) Radio

Lord 39B W144 B; Horny Hornyphon; (ID = 610240) Radio

Lord 39B W144 B; Horny Hornyphon; (ID = 1731872) Radio
Lord 39B W144 B; Horny Hornyphon; (ID = 914836) Radio Lord 39B W144 B; Horny Hornyphon; (ID = 914839) Radio
Lord 39B W144 B; Horny Hornyphon; (ID = 914841) Radio Lord 39B W144 B; Horny Hornyphon; (ID = 914842) Radio
Lord 39B W144 B; Horny Hornyphon; (ID = 914845) Radio Lord 39B W144 B; Horny Hornyphon; (ID = 1295913) Radio
Use red slider bar for more.
Lord 39B W144 B; Horny Hornyphon; (ID = 914836) Radio
Horny Hornyphon;: Lord 39B W144 B [Radio] ID = 914836 448x336
Select picture or schematic to display from thumbnails on the right and click for download.
For model Lord 39B W144 B, Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1938/1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: KK2 KF3 KBC1 KL4
Main principle Super-Heterodyne (Super in general); ZF/IF 128 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 130+2 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Lord 39B W144 B - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 490 x 368 x 252 mm / 19.3 x 14.5 x 9.9 inch
Notes Batterie-Gerät
Price in first year of sale 210.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) -- Original-techn. papers.


All listed radios etc. from Horny (Hornyphon); Wien
Here you find 865 models, 772 with images and 578 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
