For model Maestro W II-9 E121, Horny (Hornyphon); Wien:
Hornyphon Maestro

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: AF7 AL1 AZ1
Main principle TRF with regeneration; 1 AF stage(s)
Tuned circuits 1 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Maestro W II-9 E121 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 325 x 440 x 175 mm / 12.8 x 17.3 x 6.9 inch
Notes Export Schweiz (T)
Net weight (2.2 lb = 1 kg) 8.4 kg / 18 lb 8 oz (18.502 lb)
Price in first year of sale 238.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
