Neutrobaby 2-Rö

Neutrobaby 2-Rö; Horny Hornyphon; (ID = 73405) Radio Neutrobaby 2-Rö; Horny Hornyphon; (ID = 28406) Radio
Neutrobaby 2-Rö; Horny Hornyphon; (ID = 83772) Radio Neutrobaby 2-Rö; Horny Hornyphon; (ID = 83771) Radio
Neutrobaby 2-Rö; Horny Hornyphon; (ID = 83773) Radio Neutrobaby 2-Rö; Horny Hornyphon; (ID = 83774) Radio
Neutrobaby 2-Rö; Horny Hornyphon; (ID = 206603) Radio Neutrobaby 2-Rö; Horny Hornyphon; (ID = 1352908) Radio
Neutrobaby 2-Rö; Horny Hornyphon; (ID = 1352909) Radio Neutrobaby 2-Rö; Horny Hornyphon; (ID = 1352910) Radio
Use red slider bar for more.
Neutrobaby 2-Rö; Horny Hornyphon; (ID = 73405) Radio
Horny Hornyphon;: Neutrobaby 2-Rö [Radio] ID = 73405 617x381
Select picture or schematic to display from thumbnails on the right and click for download.
For model Neutrobaby 2-Rö, Horny (Hornyphon); Wien:
Hornyphon Neutrobaby 2 Röhr.

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1927/1927 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 2: A415 B443
Main principle TRF with regeneration; 1 AF stage(s); something special ? Please give information (notes)
Tuned circuits 1 AM circuit(s)
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Neutrobaby 2-Rö - Horny Hornyphon; Wien
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Horny (Hornyphon); Wien
Here you find 869 models, 777 with images and 583 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
