Neutrovox A2 ( LMK)

Neutrovox A2 ; Horny Hornyphon; (ID = 375265) Radio Neutrovox A2 ; Horny Hornyphon; (ID = 375270) Radio
Neutrovox A2 ; Horny Hornyphon; (ID = 375269) Radio Neutrovox A2 ; Horny Hornyphon; (ID = 375266) Radio
Neutrovox A2 ; Horny Hornyphon; (ID = 375268) Radio Neutrovox A2 ; Horny Hornyphon; (ID = 375271) Radio
Neutrovox A2 ; Horny Hornyphon; (ID = 375272) Radio Neutrovox A2 ; Horny Hornyphon; (ID = 375273) Radio
Neutrovox A2 ; Horny Hornyphon; (ID = 375274) Radio
Use red slider bar for more.
Neutrovox A2 ; Horny Hornyphon; (ID = 375265) Radio
Horny Hornyphon;: Neutrovox A2 [Radio] ID = 375265 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Neutrovox A2 ( LMK), Horny (Hornyphon); Wien

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1927/1928 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: A442 A415 A425 B443
Main principle TRF without regeneration
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Neutrovox A2 - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 625 x 235 x 260 mm / 24.6 x 9.3 x 10.2 inch
Notes 200-4000m
Net weight (2.2 lb = 1 kg) 8.2 kg / 18 lb 1 oz (18.062 lb)
Price in first year of sale 500.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
