Prinz 40B W135B 1939-40

Prinz 40B W135B; Horny Hornyphon; (ID = 1726764) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 9634) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 232308) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 232310) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 232314) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 232316) Radio

Prinz 40B W135B; Horny Hornyphon; (ID = 610883) Radio
Prinz 40B W135B; Horny Hornyphon; (ID = 689722) Radio Prinz 40B W135B; Horny Hornyphon; (ID = 492658) Radio
Prinz 40B W135B; Horny Hornyphon; (ID = 689724) Radio Prinz 40B W135B; Horny Hornyphon; (ID = 492657) Radio
Prinz 40B W135B; Horny Hornyphon; (ID = 492655) Radio Prinz 40B W135B; Horny Hornyphon; (ID = 492659) Radio
Prinz 40B W135B; Horny Hornyphon; (ID = 492661) Radio Prinz 40B W135B; Horny Hornyphon; (ID = 689723) Radio
Prinz 40B W135B; Horny Hornyphon; (ID = 1262423) Radio Prinz 40B W135B; Horny Hornyphon; (ID = 1335302) Radio
Use red slider bar for more.
Prinz 40B W135B; Horny Hornyphon; (ID = 689722) Radio
Horny Hornyphon;: Prinz 40B W135B [Radio] ID = 689722 800x629
Select picture or schematic to display from thumbnails on the right and click for download.
For model Prinz 40B W135B 1939-40, Horny (Hornyphon); Wien:
eigene Sammlung

Country:  Austria
Manufacturer / Brand:  Horny (Hornyphon); Wien
Brand

Hornyphon
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: KK2 KBC1 KL4
Main principle Super-Heterodyne (Super in general); ZF/IF 128 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Storage and/or dry batteries / 130+2 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Prinz 40B W135B [1939-40] - Horny Hornyphon; Wien
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 479 x 355 x 240 mm / 18.9 x 14 x 9.4 inch
Notes Anodenstrom-Sparschalter
Net weight (2.2 lb = 1 kg) 9.2 kg / 20 lb 4.2 oz (20.264 lb)
Price in first year of sale 185.00 öS
External source of data E. Erb 3-907007-36-0
Source of data Handbuch WDRG 1939 / Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Lange+Schenk+FS-Röhrenbestückung
Literature/Schematics (1) -- Original-techn. papers.
