Cosmos W 1953

Cosmos W ; Ingelen, (ID = 566770) Radio

Cosmos W ; Ingelen, (ID = 566777) Radio
Cosmos W ; Ingelen, (ID = 133982) Radio Cosmos W ; Ingelen, (ID = 133984) Radio
Cosmos W ; Ingelen, (ID = 133983) Radio Cosmos W ; Ingelen, (ID = 827158) Radio
Cosmos W ; Ingelen, (ID = 532493) Radio Cosmos W ; Ingelen, (ID = 532494) Radio
Cosmos W ; Ingelen, (ID = 532495) Radio Cosmos W ; Ingelen, (ID = 1368498) Radio
Cosmos W ; Ingelen, (ID = 1368500) Radio Cosmos W ; Ingelen, (ID = 1368502) Radio
Use red slider bar for more.
Cosmos W ; Ingelen, (ID = 133982) Radio
Ingelen,: Cosmos W [Radio] ID = 133982 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cosmos W 1953, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien:
Ingelen Cosmos W

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Super-Heterodyne (Super in general); ZF/IF 459 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Ready for FM, has Broadcast, Long Wave, Short wave.
Details
Power type and voltage Alternating Current supply (AC) / 110, 130, 150, 220, 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Cosmos W [1953] - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 390 x 227 x 180 mm / 15.4 x 8.9 x 7.1 inch
Notes Nachfolger der berühmten Columbus Serie
Net weight (2.2 lb = 1 kg) 5.2 kg / 11 lb 7.3 oz (11.454 lb)
Price in first year of sale 1,395.00 ATS
Collectors' prices
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

Model page created by Günter Denoth. See "Data change" for further contributors.
