Cosmos W ab Gerät Nr142.601

Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 1917306) Radio

Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 1917307) Radio

Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 1917309) Radio

Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 1917310) Radio

Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 1917311) Radio
Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273013) Radio Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273017) Radio
Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273012) Radio Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273014) Radio
Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273016) Radio
Use red slider bar for more.
Cosmos W ab Gerät Nr142.601; Ingelen, (ID = 2273013) Radio
Ingelen,: Cosmos W ab Gerät Nr142.601 [Radio] ID = 2273013 1400x1050
Select picture or schematic to display from thumbnails on the right and click for download.
For model Cosmos W ab Gerät Nr142.601, Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien

Country:  Austria
Manufacturer / Brand:  Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Brand

Elektrot.Fabrik Ludwig Neumann
Year: 1953 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EBC41 EL41 EM34 AZ41
Main principle Superheterodyne (common); ZF/IF 451 or 459 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 150; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Cosmos W ab Gerät Nr142.601 - Ingelen, Elektrotechnische
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes

Siehe auch Ingelen Cosmos W bis Nr. 142.600

Literature/Schematics (1) -- Original-techn. papers.

Model page created by Arpad Roth † 27.3.17. See "Data change" for further contributors.



All listed radios etc. from Ingelen, Elektrotechnische Fabrik Ing. Ludwig Neumann GmbH; Wien
Here you find 438 models, 385 with images and 318 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
