Yucatan 716-G

Yucatan 716-G; Inter Electronica S. (ID = 855433) Radio Yucatan 716-G; Inter Electronica S. (ID = 856880) Radio
Yucatan 716-G; Inter Electronica S. (ID = 1250036) Radio Yucatan 716-G; Inter Electronica S. (ID = 1250037) Radio
Yucatan 716-G; Inter Electronica S. (ID = 1250039) Radio Yucatan 716-G; Inter Electronica S. (ID = 1250041) Radio
Yucatan 716-G; Inter Electronica S. (ID = 1250043) Radio Yucatan 716-G; Inter Electronica S. (ID = 1250044) Radio
Yucatan 716-G; Inter Electronica S. (ID = 1250045) Radio
Use red slider bar for more.
Yucatan 716-G; Inter Electronica S. (ID = 855433) Radio
Inter Electronica S.: Yucatan 716-G [Radio] ID = 855433 475x356
Select picture or schematic to display from thumbnails on the right and click for download.
For model Yucatan 716-G, Inter Electronica S.A.; Barcelona

Country:  Spain
Manufacturer / Brand:  Inter Electronica S.A.; Barcelona
Year: 1954/1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH42 EAF42 EAF42 EL41 EM4 AZ41
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 90-110-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Yucatan 716-G - Inter Electronica S.A.;
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 545 x 390 x 235 mm / 21.5 x 15.4 x 9.3 inch
Notes Modelo de gama alta presentado a finales de 1954 para el catálogo de 1955. Equipado con ensanche total denominado "radarik", según la publicidad de la época.

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
