For model Kvinta, Iron-Radio, Ing. Galoda a Spol; Brno-Zidenice:
Foto: Jan Hostak, Tschechien. Vielen Dank !

Country:  Czechoslovakia
Manufacturer / Brand:  Iron-Radio, Ing. Galoda a Spol; Brno-Zidenice
Year: 1948 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECH21 EF22 EF22 EF22 EM11 EBL21 AZ1
Main principle Superheterodyne (common); ZF/IF 450 kHz
Tuned circuits 8 AM circuit(s)
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 18 cm = 7.1 inch
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Kvinta - Iron-Radio, Ing. Galoda a Spol
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 465 x 332 x 253 mm / 18.3 x 13.1 x 10 inch
Notes This model has been developed and the production began in Iron. After nationalization the prodcution ran under Tesla. The difference is only on the box and back side plate, brand sign Tesla or Iron.
Mentioned in Ceskoslovenske Rozhlasove a Televizni Prijimace I a II

Model page created by Gabriel Toth. See "Data change" for further contributors.
