Triglav 62; Iskra - Kranj (ID = 1402542) Radio
Iskra - Kranj: Triglav 62 [Radio] ID = 1402542 870x619
Select picture or schematic to display from thumbnails on the right and click for download.
For model Triglav 62, Iskra - Kranj

Country:  Yugoslavia
Manufacturer / Brand:  Iskra - Kranj
Year: 1963 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: ECC85 ECH81 EF89 EABC80 EM84 EL84 EZ80
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 2 Loudspeakers
Power out
from Radiomuseum.org Model: Triglav 62 - Iskra - Kranj
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 570 x 380 x 340 mm / 22.4 x 15 x 13.4 inch
Notes

"Emona" record player, 16-78 rpm.

Two types of cases. Larger side openings covered with cloth and lighter scale glass , or smaller hole with plastic grids instead, black scale with golden letters.

Net weight (2.2 lb = 1 kg) 18 kg / 39 lb 10.4 oz (39.648 lb)
Collectors' prices

Model page created by Peter Böhm. See "Data change" for further contributors.
