Junior 20 52330307; ITT Schaub-Lorenz (ID = 457443) Radio
ITT Schaub-Lorenz: Junior 20 52330307 [Radio] ID = 457443 693x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Junior 20 52330307, ITT Schaub-Lorenz:
Sammlung

Country:  Germany
Manufacturer / Brand:  ITT Schaub-Lorenz
Year: 1970/1971 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: CS9016 CS9018 CS9018 CS1312 CS9018 CS1312 BT1 CS1312 2SB364 2SD104 1N34A CD0000 1N60 1N60 1N34A
Main principle Superheterodyne (common); ZF/IF 455/10700 kHz
Tuned circuits 5 AM circuit(s)     7 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Dry Batteries / 4 × 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.4 W (unknown quality)
from Radiomuseum.org Model: Junior 20 52330307 - ITT Schaub-Lorenz
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 157 x 97 x 45 mm / 6.2 x 3.8 x 1.8 inch
Notes

MW: 510 - 1605 kHz
UKW: 87,5 -104 MHz

Parallelgerät zum Junior 20 52330305.

Literature/Schematics (1) -- Original-techn. papers.
