42A

42A; Jura; La Chaux-de- (ID = 2350353) Radio
42A; Jura; La Chaux-de- (ID = 1770) Radio 42A; Jura; La Chaux-de- (ID = 23832) Radio
Use red slider bar for more.
42A; Jura; La Chaux-de- (ID = 1770) Radio
Jura; La Chaux-de-: 42A [Radio] ID = 1770 700x501
Select picture or schematic to display from thumbnails on the right and click for download.
For model 42A, Jura; La Chaux-de-Fonds (eigentlich Zürich)

Country:  Switzerland
Manufacturer / Brand:  Jura; La Chaux-de-Fonds (eigentlich Zürich)
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: AK2 AF3 AB2 AL4 AZ1
Main principle Superheterodyne (common); ZF/IF 128 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: 42A - Jura; La Chaux-de-Fonds
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Sch=456A;
Price in first year of sale 315.00 SFr
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die Tungsram-Tabellen führen das Modell auf.
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
