For model Amicus MW + NW, Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien:
Kapsch Amicus

Country:  Austria
Manufacturer / Brand:  Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien
Year: 1960/1961 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: OC169 OC169 OC169 OC171 OC71 OC72 OC72
Main principle Superheterodyne (common); ZF/IF 480 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 11 cm = 4.3 inch
Power out 0.2 W (unknown quality)
from Radiomuseum.org Model: Amicus MW + NW - Kapsch & Söhne KS, Telephon-
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 222 x 149 x 69 mm / 8.7 x 5.9 x 2.7 inch
Notes Beide Modell-Typen lassen sich durch hinterlegte Schaltpläne nachweisen. Laut dem Schaltplan vom Modell NM sind Transistoren der Type ADxx verbaut, jedoch im Plan nicht verbessert.
Lieferbar in den Farben: Sand, Blau, Rot und Grün.
Net weight (2.2 lb = 1 kg) 1.3 kg / 2 lb 13.8 oz (2.863 lb)
Price in first year of sale 995.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb
Mentioned in RADIOBOTE, Österr. (Heft 53/2014, S.15 ff, Gerätebeschreibung)
Literature/Schematics (1) -- Schematic
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
