Troubadour TR - Changer

• Country
• Austria

• Manufacturer / Brand
• Kapsch & Söhne (KS), Telephon- und Telegraphenfabriks-AG; Wien

• Year
• 1969/1970 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 73701

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 13

• Semiconductors
• BF195 BF195 BF167 BF167 BF167 BF167 BC149 BC149 BC158 AC117 AC175 AD155 ANM BY164

• Main principle
• Superheterodyne (common); ZF/IF 462/10700 kHz; 6 AF stage(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Troubadour TR - Changer - Kapsch & Söhne KS, Telephon-

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Notes
• • Einbaulaufwerk: Dual 1210
  • Anschlüsse:
    • Phono/Tonband-Wiedergabe und Tonband-Aufnahme (DIN)
    • LS Anschluss schaltbar (DIN)
    • Antenne
  • wichtige Bauteile:
    • Skalenlämpchen 18V 0,1A

  Siehe auch:

  • Troubadour TR nur Radio
  • Troubadour TR Phono dieses Modell mit Plattenspieler

• Source of data
• -- Original-techn. papers. / Radiokatalog Band 2, Ernst Erb

• Author
• Model page created by Wolfgang Bauer. See "Data change" for further contributors.
