Stradivari (II) DW5422

Stradivari DW5422; Kiraco Welt-Radio (ID = 2066248) Radio

Stradivari DW5422; Kiraco Welt-Radio (ID = 2066249) Radio
Stradivari DW5422; Kiraco Welt-Radio (ID = 2946) Radio Stradivari DW5422; Kiraco Welt-Radio (ID = 11810) Radio
Stradivari DW5422; Kiraco Welt-Radio (ID = 11809) Radio Stradivari DW5422; Kiraco Welt-Radio (ID = 11811) Radio
Stradivari DW5422; Kiraco Welt-Radio (ID = 532885) Radio Stradivari DW5422; Kiraco Welt-Radio (ID = 532887) Radio
Stradivari DW5422; Kiraco Welt-Radio (ID = 534752) Radio Stradivari DW5422; Kiraco Welt-Radio (ID = 534753) Radio
Stradivari DW5422; Kiraco Welt-Radio (ID = 534754) Radio Stradivari DW5422; Kiraco Welt-Radio (ID = 534755) Radio
Use red slider bar for more.
Stradivari DW5422; Kiraco Welt-Radio (ID = 2946) Radio
Kiraco Welt-Radio: Stradivari DW5422 [Radio] ID = 2946 933x634
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stradivari (II) DW5422, Kiraco Welt-Radio GmbH (Kisters); Meersburg bzw. Konstanz

Country:  Germany
Manufacturer / Brand:  Kiraco Welt-Radio GmbH (Kisters); Meersburg bzw. Konstanz
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 12: EF80 EC92 EF41 ECH42 EM34 EAF42 EF85 EB41 EF40 EL41 EL41 AZ12
Main principle Superhet with RF-stage
Tuned circuits 8 AM circuit(s)     11 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Stradivari DW5422 - Kiraco Welt-Radio GmbH Kisters
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 650 x 435 x 295 mm / 25.6 x 17.1 x 11.6 inch
Notes Klaviertasten (8) dienen als Tonregister. Verkauft man in der Schweiz unter «Triumpf Favorit». Separate tuning for AM and UKW Band, precise tuning on short wave. Amplifier with two EL41 in parallel connection.
Net weight (2.2 lb = 1 kg) 15.8 kg / 34 lb 12.8 oz (34.802 lb)
Price in first year of sale 498.00 DM
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in Historische Radios Band III (123)
Picture reference Das Gerät ist im Doppelband "Historische Radios" von Günther Abele abgebildet.


All listed radios etc. from Kiraco Welt-Radio GmbH (Kisters); Meersburg bzw. Konstanz
Here you find 10 models, 8 with images and 4 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
