Commodore KR022

Commodore KR022; Kolster Brandes Ltd. (ID = 1317094) Radio

Commodore KR022; Kolster Brandes Ltd. (ID = 1317095) Radio
Commodore KR022; Kolster Brandes Ltd. (ID = 1403860) Radio Commodore KR022; Kolster Brandes Ltd. (ID = 2275174) Radio
Commodore KR022; Kolster Brandes Ltd. (ID = 1065301) Radio Commodore KR022; Kolster Brandes Ltd. (ID = 1065302) Radio
Commodore KR022; Kolster Brandes Ltd. (ID = 1065303) Radio Commodore KR022; Kolster Brandes Ltd. (ID = 1065304) Radio
Commodore KR022; Kolster Brandes Ltd. (ID = 1065305) Radio Commodore KR022; Kolster Brandes Ltd. (ID = 1362403) Radio
Commodore KR022; Kolster Brandes Ltd. (ID = 1403861) Radio Commodore KR022; Kolster Brandes Ltd. (ID = 1403862) Radio
Use red slider bar for more.
Commodore KR022; Kolster Brandes Ltd. (ID = 1403860) Radio
Kolster Brandes Ltd.: Commodore KR022 [Radio] ID = 1403860 933x561
Select picture or schematic to display from thumbnails on the right and click for download.
For model Commodore KR022, Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

Country:  Great Britain (UK)
Manufacturer / Brand:  Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Year: 1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 7: AF117 AF117 OC70 AC157 AC157 AC113 AC154
Main principle Superheterodyne (common); ZF/IF 470 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Commodore KR022 - Kolster Brandes Ltd. KB, K.B.,
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 310 x 175 x 75 mm / 12.2 x 6.9 x 3 inch
Notes

MW is spread between 2 bands giving "bandspread" on both the high and low wavelengths.
Alternative transistors found in the "Brown" example seen above in photo ID=2275174 serial number 1278/11805, are AF127 AF127 OC70 AC127 AC128 AC127 AC128.
In the "Grey" example photo ID=1403860 serial number 1278/04212, alternative transistors were; AF117 AF127 AC151 AC127 AC128 AC127 AC128

Battery type; PP9.
Dimensions do not include knobs and handle.

Same chassis as RGD RR222 "Rambler"

Price in first year of sale 19.16 UK £
Mentioned in -- Original-techn. papers. (Date and price from Radio Radio, (Hill), page 260)

Model page created by Peter Hoddow. See "Data change" for further contributors.
