Amatus 40WKD

Amatus 40WKD; Körting-Radio; (ID = 1006875) Radio

Amatus 40WKD; Körting-Radio; (ID = 4693) Radio

Amatus 40WKD; Körting-Radio; (ID = 2104591) Radio

Amatus 40WKD; Körting-Radio; (ID = 2104595) Radio

Amatus 40WKD; Körting-Radio; (ID = 2104628) Radio

Amatus 40WKD; Körting-Radio; (ID = 2105103) Radio

Amatus 40WKD; Körting-Radio; (ID = 2105104) Radio

Amatus 40WKD; Körting-Radio; (ID = 2105105) Radio
Amatus 40WKD; Körting-Radio; (ID = 1380219) Radio Amatus 40WKD; Körting-Radio; (ID = 1380225) Radio
Amatus 40WKD; Körting-Radio; (ID = 1380222) Radio Amatus 40WKD; Körting-Radio; (ID = 1380226) Radio
Amatus 40WKD; Körting-Radio; (ID = 1469678) Radio Amatus 40WKD; Körting-Radio; (ID = 1469679) Radio
Amatus 40WKD; Körting-Radio; (ID = 1469680) Radio Amatus 40WKD; Körting-Radio; (ID = 1469681) Radio
Amatus 40WKD; Körting-Radio; (ID = 258120) Radio Amatus 40WKD; Körting-Radio; (ID = 258122) Radio
Use red slider bar for more.
Amatus 40WKD; Körting-Radio; (ID = 1380219) Radio
Körting-Radio;: Amatus 40WKD [Radio] ID = 1380219 933x733
Select picture or schematic to display from thumbnails on the right and click for download.
For model Amatus 40WKD, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH11 EBF11 EF11 EL11 EM11 AZ11
Main principle Superheterodyne (common); ZF/IF 468 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Amatus 40WKD - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 537 x 440 x 318 mm / 21.1 x 17.3 x 12.5 inch
Notes

8 Stationstasten, variable Bandbreitenreglung

Abgleich siehe Amatus 40WK

Net weight (2.2 lb = 1 kg) 17.6 kg / 38 lb 12.3 oz (38.767 lb)
Price in first year of sale 335.00 RM
Source of data Handbuch WDRG 1939 / Radiokatalog Band 1, Ernst Erb
Circuit diagram reference Lange-Nowisch
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.
