Excello 3950

Excello 3950; Körting-Radio; (ID = 508089) Radio

Excello 3950; Körting-Radio; (ID = 508090) Radio

Excello 3950; Körting-Radio; (ID = 1741466) Radio
Excello 3950; Körting-Radio; (ID = 391502) Radio Excello 3950; Körting-Radio; (ID = 392317) Radio
Excello 3950; Körting-Radio; (ID = 391501) Radio Excello 3950; Körting-Radio; (ID = 392318) Radio
Excello 3950; Körting-Radio; (ID = 392319) Radio Excello 3950; Körting-Radio; (ID = 392321) Radio
Excello 3950; Körting-Radio; (ID = 462985) Radio Excello 3950; Körting-Radio; (ID = 462986) Radio
Excello 3950; Körting-Radio; (ID = 462987) Radio Excello 3950; Körting-Radio; (ID = 462988) Radio
Use red slider bar for more.
Excello 3950; Körting-Radio; (ID = 391502) Radio
Körting-Radio;: Excello 3950 [Radio] ID = 391502 931x582
Select picture or schematic to display from thumbnails on the right and click for download.
For model Excello 3950, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1958 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: ECC85 ECH81 EF89 EABC80 EM84 EL84 EL84 EZ81
Main principle Superheterodyne (common); ZF/IF 472/10700 kHz; 2 AF stage(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 155; 220; 240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Excello 3950 - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 610 x 355 x 265 mm / 24 x 14 x 10.4 inch
Notes Tasten: Sprache, Orchester, Tanz, Stereo
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 399.00 DM
Source of data -- Collector info (Sammler)
Mentioned in Taxliste Franzis Verlag

Model page created by Ralf Wäschenbach. See "Data change" for further contributors.



All listed radios etc. from Körting-Radio; Leipzig, später Grassau
Here you find 727 models, 575 with images and 422 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
