• Country
• Germany

• Manufacturer / Brand
• Körting-Radio; Leipzig, später Grassau

• Year
• 1957 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 283694

• • alternative name: Dietz & Ritter GmbH, Dr.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EM84 EZ81 EL84 EL84

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110: 127: 220: 240 Volt

• Loudspeaker
• 4 Loudspeakers

• from Radiomuseum.org
• Model: Tonmeister - Körting-Radio; Leipzig, später

• Literature/Schematics (2)
• -- Schematic

• Author
• Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
