Alassio Ch= 666

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494745) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494752) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494753) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494754) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494755) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494756) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494757) Radio

Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 2494760) Radio
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1668784) Radio Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 58488) Radio
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1668783) Radio Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1668785) Radio
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1668786) Radio Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1669176) Radio
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1669177) Radio Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1669178) Radio
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1669179) Radio
Use red slider bar for more.
Alassio Ch= 666; Kuba Kuba-Imperial, (ID = 1668784) Radio
Kuba Kuba-Imperial,: Alassio Ch= 666 [Radio] ID = 1668784 818x613
Select picture or schematic to display from thumbnails on the right and click for download.
For model Alassio Ch= 666, Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel:
Gerät, Frontklappen geöffnet

Country:  Germany
Manufacturer / Brand:  Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
alternative name

Imperial Kuba
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EAF801 ECC83 EMM803 ELL80
Semiconductors (the count is only for transistors) 1: AF137
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Alassio Ch= 666 - Kuba Kuba-Imperial, G.
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1400 x 795 x 400 mm / 55.1 x 31.3 x 15.7 inch
Notes Rundfunk-Chassis = 666, Stereo-Decoder R101 nachrüstbar, Stereo-NF-Verstärker mit 2 Endstufen je 3 W;
Phono-Chassis = BSR UA15SS3D.
External source of data erb
Source of data Handbuch VDRG 1966/1967 / Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
Here you find 726 models, 673 with images and 270 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
