Ascona Ch= 664

Ascona Ch= 664; Kuba Kuba-Imperial, (ID = 559957) Radio

Ascona Ch= 664; Kuba Kuba-Imperial, (ID = 559958) Radio

Ascona Ch= 664; Kuba Kuba-Imperial, (ID = 559959) Radio
Ascona Ch= 664; Kuba Kuba-Imperial, (ID = 814574) Radio
Use red slider bar for more.
Ascona Ch= 664; Kuba Kuba-Imperial, (ID = 814574) Radio
Kuba Kuba-Imperial,: Ascona Ch= 664 [Radio] ID = 814574 933x524
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ascona Ch= 664, Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel:
Kuba Katalog 64/65 - Sammlung Funkhistorisches Archiv der GFGF e.V.

Country:  Germany
Manufacturer / Brand:  Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
alternative name

Imperial Kuba
Year: 1964/1965 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EAF801 ECC83 EM84 ELL80
Semiconductors (the count is only for transistors) 1: AF137
Main principle Superheterodyne (common)
Tuned circuits 6 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Changer (Record changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: Ascona Ch= 664 - Kuba Kuba-Imperial, G.
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 1450 x 730 x 380 mm / 57.1 x 28.7 x 15 inch
Notes Rundfunk-Chassis = Imperial 664;
Phono-Chassis von verschiedenen Herstellern.
Price in first year of sale 1'150.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965 / Radiokatalog Band 2, Ernst Erb
