Farbfernsehempfänger Chassis Ch= C426
Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Country
- Germany
- Manufacturer / Brand
- Kuba (Kuba-Imperial), G. Kubetschek; Wolfenbüttel
- Year
- 1970
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 274790
-
- alternative name: Imperial Kuba
Picture from Kuba manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 13
- Number of Transistors
- 37
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: Farbfernsehempfänger Chassis Ch= C426 - Kuba Kuba-Imperial, G.
- Shape
- Chassis only or for «building in»
- Notes
-
VHF/UHF Kanalwähler Typ ET100.
Der Type der Bildröhre ist unsicher: im Schema wird A65-120X genannt, wohingegen die Ersatzteilliste die Type A66-120X führt.
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
