Renas r/2

LESA ; Milano

Data
Forum
Pictures
Collections

  • Year
  • 1963/1964
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 197889

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Number of Transistors
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Details
  • Tape Recorder
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 125; 140; 160; 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2.5 W (unknown quality)
  • from Radiomuseum.org
  • Model: Renas r/2 - LESA ; Milano
  • Shape
  • Tablemodel, with any shape - general.
  • Notes

  • Risposta in frequenza:
    Velocità 9,53 cm/sec: 50 - 12000 Hz
    Velocità 4,76 cm/sec: 50 - 7000 Hz
    Velocità 2,38 cm/sec: gamma telefonica

    Ingressi:
    Fono o radio 1 mV / 0,22 MOhm
    Fono 50 mV / 0,47 MOhm

    Uscita cuffia impedenza 22 kOhm.

  • Price in first year of sale
  • 71,500.00 ITL
  • Literature/Schematics (2)
  • -- Original prospect or advert (Selezione radio-tv Marzo 1964)
  • Literature/Schematics (3)
  • -- Original prospect or advert (Epoca, Vol. 14, 1963)
  • Author
  • Model page created by Eduard Abfalterer. See "Data change" for further contributors.
