Arosa 53 110 mattiert

Arosa 53 110; Loewe-Opta; (ID = 380812) Television

Arosa 53 110; Loewe-Opta; (ID = 380813) Television

Arosa 53 110; Loewe-Opta; (ID = 380814) Television

Arosa 53 110; Loewe-Opta; (ID = 738508) Television

Arosa 53 110; Loewe-Opta; (ID = 738509) Television

Arosa 53 110; Loewe-Opta; (ID = 738517) Television

Arosa 53 110; Loewe-Opta; (ID = 738518) Television

Arosa 53 110; Loewe-Opta; (ID = 738519) Television

Arosa 53 110; Loewe-Opta; (ID = 738520) Television
Use red slider bar for more.
Arosa 53 110; Loewe-Opta; (ID = 380812) Television
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1964/1965 Category: Television Receiver (TV) or Monitor
Valves / Tubes 13: PC900 PCF801 EF183 EF80 PCL84 PCH200 PCL85 PL500 PY88 DY86 PCL86 PCF802 A59-11W
Semiconductors (the count is only for transistors) 4:
Main principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details Radio Control (+Remote Wire etc)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: Arosa 53 110 [mattiert] - Loewe-Opta; Deutschland
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 810 x 890 x 355 mm / 31.9 x 35 x 14 inch
Notes VHF/UHF.
Net weight (2.2 lb = 1 kg) 46 kg / 101 lb 5.1 oz (101.322 lb)
Price in first year of sale 1'480.00 DM
External source of data Erb
Source of data Handbuch VDRG 1964/1965


All listed radios etc. from Loewe-(Opta); Deutschland
Here you find 1563 models, 1291 with images and 1144 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
